EMD1 (EnMesh Dot)

The EnGenius EMD1 (EnMesh Dot) router has Gigabit WiFi, 1 Gigabit ETH-ports and 0 USB-ports. It has a total combined WiFi throughput of 1300 Mpbs.

Quick links:
Default password/Login
Login instructions
User Manuals



EMD1 (EnMesh Dot) router specifications (specs)

System specs
CPU: 710 MHz
RAM: 256 MiB
Flash: 32 MiB
Custom firmwares: None
Connectivity
WiFi: Gigabit (abgn+ac)
WiFi bands: 2.4GHz & 5GHz
WiFi throughput: 1300 Mpbs
WAN: None
ETH: 1 x Gigabit port
USB-ports: 0

Hard reset instructions for EnGenius EMD1 (EnMesh Dot)

If your EMD1 (EnMesh Dot) router is not working as it should, dropping connections or not being responsive, you should first do a reset of the router to see if the problems persist. Other scenarios where you might want to reset your router is if you've forgotten the password or misconfigured it and can't get access anymore.
Your can reset your EnGenius EMD1 (EnMesh Dot) in the following way(s):

Through the web interface

  1. Open a web browser and go to the address of the router (check default settings below)
  2. Sign in with your username/password, if unchanged check default settings below
  3. Locate Management in the menu and click it
  4. Click on Configure
  5. On the Configure page click on the Reset button, if prompted click Ok
  6. Wait for router to reboot

With the reset button

  1. Have the router plugged in and turned on
  2. Locate the reset button (it's usually labeled reset or RESET/WPS)
  3. With a sharp object, for example a paperclip, press and hold the reset button for at least 11 seconds
  4. When the POWER led starts blinking release the reset button
  5. Wait for the router to reboot.

The 30-30-30 reset

If the above instructions don't work you can always try the 30-30-30 reset as follows:
  1. When router is powered on, press the reset button and hold for 30 seconds. (Use a paper clip or something sharp)
  2. While holding the reset button pressed, unplug the power of the router and hold the reset button for 30 seconds
  3. While still holding the reset button down, turn on the power to the unit again and hold for another 30 seconds.

This process usually works for resetting any router to it's factory setting.

Note: It is worth reading more about how to reset routers with the 30 30 30 reset and what the risks and considerations are when resetting your router this way, instead of just rebooting it.


Default factory settings for EnGenius EMD1 (EnMesh Dot)

If you have performed a reset of your EMD1 (EnMesh Dot) device or not changed the defaults, you should be able to access it with the following settings:

Default Gateway IP: 192.168.1.1 EnGenius login instructions
Default username: admin EnGenius router default password list
Default password: adminĀ
Default subnet mask: 255.255.255.0
Default DNS server: 192.168.1.1
Note: If you are using the default settings you should change them to increase security and prevent unathorized access to your network.

How to login to the EMD1 (EnMesh Dot)

To login to the EMD1 (EnMesh Dot) router and change the settings, you can follow these steps:

  1. Make sure you are connected to the router's network, either by Wi-Fi or ethernet cable.
  2. Open your browser and visit http://192.168.1.1
  3. You should be prompted with a login dialogue.
  4. Enter the username: admin and the password admin
    Note: If you have already changed the password use that instead.
  5. You will now be logged in. If you haven't yet changed the defaul password, we recommend that you change it first thing you do after logging in.

If these instructions don't work for your router, you can always try a factory reset to get the default, or try some other common EnGenius credentials, as they can usually be shared across models/variants.
